Corundum mullite high-strength wear-resistant refractory castables have high compressivestrength, good high temperature volume stability and thermal stability, excellent wear resistance and strong corrosion resistance.
Corundum mullite high-strength wear-resistant refractory castables have high compressivestrength, good high temperature volume stability and thermal stability, excellent wear resistance and strong corrosion resistance. Can be used for the lining of large CFB boilerwear linings and other hightemperature furnaces.
|
Item |
MGM-1 |
MGM-2 |
MGM-3 |
|
|
AL2O3% ≥ |
70 |
75 |
85 |
|
|
SiO2 % ≤ |
25 |
17 |
13 |
|
|
Fe2O3 % ≤ |
1 |
1 |
1 |
|
|
Bulk density g/cm3 ≥ |
2.7 |
2.8 |
2.9 |
|
|
Flexural strength MPa ≥
|
110℃×24h |
10 |
11 |
12 |
|
1100℃×3h |
16 |
17 |
18 |
|
|
1400℃×3h |
17 |
18 |
19 |
|
|
Compressive strength/ MPa ≥
|
110℃×24h |
75 |
85 |
95 |
|
1100℃×3h |
100 |
110 |
120 |
|
|
1400℃×3h |
115 |
120 |
125 |
|
|
Normal wear cm3 ≤ |
7 |
6 |
5 |
|
|
0.2MPa load softening start temperature/℃≥ |
1450 |
1480 |
1500 |
|
|
Thermal shock stability TSR (900℃ ,water cooling) time≥ |
25 |
25 |
25 |
|
|
PLC /% ≤ |
-0.3 |
-0.2 |
-0.2 |
|
|
Maximum Service temperature/℃ |
1550 |
1550 |
1600 |
|
The manufacturing technique of phosphate refractory bricks is same as phosphate castable. With rapid development recent years, phosphate refractory brick is remarkably effective in cement kiln and electric furnace roof.
The silica mullite firebrick produced by our company is made from high-grade bauxite clinker and high-quality silicon carbide as the main raw materials and firing at high temperature.
Monolithic castables for ladle safety lining are composed of corundum, high quality bauxite, superfine powder and other ingredients and featured with good work ability on site casting, high strength, high volume stability and long life span.
