Nobaking ramming mass for iron notch is made of corundum, high quality bauxite and silicon carbide, and bonded by resins and tar. Installation can be done by ramming.
Nobaking ramming mass for iron notch is made of corundum, high quality bauxite and silicon carbide, and bonded by resins and tar. Installation can be done by ramming. Nobaking ramming mass for iron notch is easy to be installed, pre-firing free, good slag erosion resistance and excellent thermal shock resistance. Nobaking ramming mass for iron notch can be applied to install and repair the iron runner of the blast furnace under 1000m3.
|
Product code |
CH-TGD-50 |
CH-TGD-55 |
CH-TGD-65 |
|
Al2O3/% |
≥50 |
≥55 |
|
|
SIC+C% |
≥20 |
≥15 |
|
|
Bulk density/g.cm3 |
≥2.3（200℃，24h） |
≥2.4（200℃，24h） |
|
|
Cold crushing strength/Mpa
|
≥8(200℃，24h) |
≥10（200℃，24h） |
≥15（200℃，24h） |
|
≥8(1450℃，3h) |
≥10(1450℃，3h) |
≥15(1450℃，3h) |
|
|
Modulus of rupture/MPa
|
≥3(200℃，24h) |
≥4(200℃，24h) |
≥5(200℃，24h) |
|
≥3(1450℃，3h) |
≥4(1450℃，24h) |
≥3(1450℃，24h) |
|
|
Permanent linear change／％ |
±1.0（1450,3h） |
±0.8（1450,3h） |
±0.8（1450,3h） |
|
Application |
Slag runner of small size blast furnace |
iron runner of small size blast furnace |
iron runner of middle or small size blast furnace |
Castable for carbon calcined rotary kiln has the advantages of high strength, high wear resistance, anti-flaking and anti-scouring. Castable for carbon calcined rotary kiln is suitable for rotary kiln kiln mouth, pre-tropical zone, calcination zone, cooling machine, feed nozzle and other parts.
Siliceous refractory repair material has high load-softening point, low temperature creep rate, high strength, low porosity, strong thermal shock resistance, anti-slag and anti-erosion, and will not damage the repaired structure due to expansionof quartz.
Electro-fused AZS refractory ramming mass is monolithic refractories and electro-fused AZS refractory ramming mix is composed of molten corundum aggregate particles and a small amount of additives.
